Air-tight Push Fit System

No need for ducting tape our ducting simply pushes together and is self-sealing, you only need to use ducting tape when you are using any of the flexible aluminium or plastic flexible hoses

At Luxair, based on extensive product testing, we recommend the following guidelines for ducting size based on your extractor’s motor airflow rate:

• For motors rated below 450 m³/hr, use 100mm (4") ducting or 125mm ducting using the reducer collars.
• For motors rated between 450 m³/hr and 750 m³/hr, use 125mm (5") or 150mm (6") ducting.
• For motors rated between 750 m³/hr and 2000 m³/hr, use 150mm (6") or 200mm (8") ducting.
• Both flat and round ducting are suitable for wall-mounted and island cooker hoods.

Following these recommendations ensures optimal extractor performance and efficiency.

Some of our more premium wall mounted hoods, such as the Lusso range and the external motors with motor ratings of 2000m³/hr must be installed on either 150mm or 200mm ducting due to the very powerful extraction rates. .

Its our recommendation that when fitting ceiling cooker hoods, its always advisable to use 6" ( 150mm ) round ducting or the equivalent 220mm x 90mm flat channel pipe.
